The Deepwater Horizon oil rig explosion, fire, and uncontrolled release of oil into the Gulf is a disaster of unprecedented magnitude. This disaster in the Gulf of Mexico appears to be more serious in objective terms than the Challenger space shuttle disaster in 1986 — in terms both of immediate loss of life and in terms of overall harm created. And sadly, it appears likely that the accident will reveal equally severe failures of management of enormously hazardous processes, defects in the associated safety engineering analysis, and inadequacies of the regulatory environment within which the activity took place. The Challenger disaster fundamentally changed the ways that we thought about safety in the aerospace field. It is likely that this disaster too will force radical new thinking and new procedures concerning how to deal with the inherently dangerous processes associated with deep-ocean drilling.
Nancy Leveson is an important expert in the area of systems safety engineering, and her book, Safeware: System Safety and Computers, is a genuinely important contribution. Leveson led the investigation of the role that software design might have played in the Challenger disaster (link). Here is a short, readable white paper of hers on system safety engineering (link) that is highly relevant to the discussions that will need to occur about deep-ocean drilling. The paper does a great job of laying out how safety has been analyzed in several high-hazard industries, and presents a set of basic principles for systems safety design. She discusses aviation, the nuclear industry, military aerospace, and the chemical industry; and she points out some important differences across industries when it comes to safety engineering. Here is an instructive description of the safety situation in military aerospace in the 1950s and 1960s:
Within 18 months after the ﬂeet of 71 Atlas F missiles became operational, four blew up in their silos during operational testing. The missiles also had an extremely low launch success rate. An Air Force manual describes several of these accidents:
An ICBM silo was destroyed because the counterweights, used to balance the silo elevator on the way up and down in the silo, were designed with consideration only to raising a fueled missile to the surface for ﬁring. There was no consideration that, when you were not ﬁring in anger, you had to bring the fueled missile back down to defuel.
The ﬁrst operation with a fueled missile was nearly successful. The drive mechanism held it for all but the last ﬁve feet when gravity took over and the missile dropped back. Very suddenly, the 40-foot diameter silo was altered to about 100-foot diameter.
During operational tests on another silo, the decision was made to continue a test against the safety engineer’s advice when all indications were that, because of high oxygen concentrations in the silo, a catastrophe was imminent. The resulting ﬁre destroyed a missile and caused extensive silo damage. In another accident, ﬁve people were killed when a single-point failure in a hydraulic system caused a 120-ton door to fall.
Launch failures were caused by reversed gyros, reversed electrical plugs, bypass of procedural steps, and by management decisions to continue, in spite of contrary indications, because of schedule pressures. (from the Air Force System Safety Handbook for Acquisition Managers, Air Force Space Division, January 1984)
Leveson’s illustrations from the history of these industries are fascinating. But even more valuable are the principles of safety engineering that she recapitulates. These principles seem to have many implications for deep-ocean drilling and associated technologies and systems. Here is her definition of systems safety:
System safety uses systems theory and systems engineering approaches to prevent foreseeable accidents and to minimize the result of unforeseen ones. Losses in general, not just human death or injury, are considered. Such losses may include destruction of property, loss of mission, and environmental harm. The primary concern of system safety is the management of hazards: their identiﬁcation, evaluation, elimination, and control through analysis, design and management procedures.
- System safety emphasizes building in safety, not adding it on to a completed design.
- System safety deals with systems as a whole rather than with subsystems or components.
- System safety takes a larger view of hazards than just failures.
- System safety emphasizes analysis rather than past experience and standards.
- System safety emphasizes qualitative rather than quantitative approaches.
- Recognition of tradeoﬀs and conﬂicts.
- System safety is more than just system engineering.
And here is an important summary observation about the complexity of safe systems:
Safety is an emergent property that arises at the system level when components are operating together. The events leading to an accident may be a complex combination of equipment failure, faulty maintenance, instrumentation and control problems, human actions, and design errors. Reliability analysis considers only the possibility of accidents related to failures; it does not investigate potential damage that could result from successful operation of the individual components.
How do these principles apply to the engineering problem of deep-ocean drilling? Perhaps the most important implications are these: a safe system needs to be based on careful and comprehensive analysis of the hazards that are inherently involved in the process; it needs to be designed with an eye to handling those hazards safely; and it can’t be done in a piecemeal, “fly-test-fly” fashion.
What elevates this accident to a globally important catastrophe is what happened next: destruction of the pipeline leading from the wellhead 5,000 feet below sea level to containers on the surface; and the failure of the shutoff valve system on the ocean floor. These two failures have resulted in unconstrained release of a massive and uncontrollable flow of crude oil into the Gulf and the likelihood of environmental harms that are likely to be greater than the Exxon Valdez.
Oil wells fail on the surface, and they are difficult to control. But there is a well-developed technology that teams of oil fire specialists like Red Adair employ to cap the flow and end the damage. We don’t have anything like this for wells drilled under water at the depth of this incident; this accident is less accessible than objects in space for corrective intervention. So surface well failures conform to a sort of epsilon-delta relationship: an epsilon accident leads to a limited delta harm. This deep-ocean well failure in the Gulf is catastrophically different: the relatively small incident on the surface is resulting in an unbounded and spiraling harm.
So was this a foreseeable hazard? Of course it was. There was always a finite probability of total loss of the platform, leading to destruction of the pipeline. There was also a finite probability of failure of the massive sea-floor emergency shutoff valve. And, critically, it was certainly known that there is no high-reliability fix in the event of failure of the shutoff valve. The effort to use the dome currently being tried by BP is untested and unproven at this great depth. The alternative of drilling a second well to relieve pressure may work; but it will take weeks or months. So essentially, when we reach the end of this failure pathway, we arrive at this conclusion: catastrophic, unbounded failure. If you reach this point in the fault tree, there is almost nothing to be done. And this is a totally irrational outcome to tolerate; how could any engineer or regulatory agency have accepted the circumstances of this activity, given that one possible failure pathway would lead predictably to unbounded harms?
There is one line of thought that might have led to the conclusion that deep ocean drilling is acceptably safe: engineers and policy makers might have optimistically overestimated the reliability of the critical components. If we estimate that the probability of failure of the platform is 1/1000, failure of the pipeline is 1/100, and failure of the emergency shutoff valve is 1/10,000 — then one might say that the probability of the nightmare scenario is vanishingly small: one in a billion. Perhaps one might reason that we can disregard scenarios with this level of likelihood. Reasoning very much like this was involved in the original safety designs of the shuttle (Safeware: System Safety and Computers). But several things are now clear: this disaster was not virtually impossible. In fact, it actually occurred. And second, it seems likely enough that the estimates of component failure are badly understated.
What does this imply about deep ocean drilling? It seems inescapable that the current state of technology does not permit us to take the risk of this kind of total systems failure. Until there is a reliable and reasonably quick technology for capping a deep-ocean well, the small probability of this kind of failure makes the use of the technology entirely unjustifiable. It makes no sense at all to play Russian roulette when the cost of failure is massive and unconstrained ecological damage.
There is another aspect of this disaster that needs to be called out, and that is the issue of regulation. Just as the nuclear industry requires close, rigorous regulation and inspection, so deep-ocean drilling must be rigorously regulated. The stakes are too high to allow the oil industry to regulate itself. And unfortunately there are clear indications of weak regulation in this industry (link).
